ELCO ERT812CT5W - 8" Ultra Slim Round LED Panel Light with 5-CCT Switch - 26W - 5-CCT 27/30/35/40/50K - 120V - Dimmable - White/White

CUSTOMER REVIEWS

Download The Spec Sheet

Price: $62.90

Qty:

Description

Technical Specs

Shipping Time

Part Number: ERT812CT5W

Triac/ELV/Dimmable

Wattage - 26w
Voltage - 120v
Lumens - 2,200lm
Selectable CCT - 27/30/35/40/50K
Finish - White/White

Height - 1 1/8"
Inner Diameter - 6 3/8"
Outer Diameter - 9"

IC Airtight for use with direct contact to insulation
Designed to fit in plenums as shallow as 2"
Remodel applications require no additional accessories
Eliminates the need for housing
New Construction application requires mounting plate or frame
Replaces 220W Incandescent
Optional ELCO Accessories: Battery Backup: Sold Separately!
5 year limited factory warranty
ETL Listed for Wet Locations and allows for use indoors or outdoors
Meets ENERGY STAR requirements, Airtight Certified Per ASTM E-283-2004
IC Airtight Rated for direct contact with insulation
CA JA8-2016-E Title 24 Compliant

Features

The ELCO 8" Ultra Slim Round LED Panel Light with 5-CCT Switch
LED Driver
- IC rated driver and fixture are tested and approved for direct contact with insulation.
- Isolated driver integrated inside aluminum remote box with two (2) 7/8" knockouts with slots for pry-out.
- Plenum rated cable connector to connect from module to remote driver box.
- Standard input wattage is 26w. Replaces 220 watt incandescent.
Features
- Polycarbonate lens diffuses light evenly throughout space with no LED pixilation.
- Maximum hole size should not exceed 8 1/4" for this product. Suitable installation for T-grid and drop ceiling applications.
- To be used with ceiling thicknesses up to 1 1/4" (two layers of 5/8" drywall).
- Designed for super shallow ceiling plenums without any housing.
- Hole cut out template provided for proper trim installation.
- Works with 120V Triac and ELV type dimmers. Dims down to 10%.
- For full list of dimmers, refer to ELCO ELM System Dimmer Compatibility List.
Listings
- IC-Rated for direct contact with insulation
- Air-tight Certified in accordance with ASTM E-283-2004
- CA Title 24 Compliant (JA8-2016-E)
- ETL Listed for Wet locations, Meets Energy Star requirements
Specifications
- 26W
- 2,200LM
- 90+ CRI
