Part Number: 09734
Description Part Number: LED14WT8/P/48/850-G8D
NON-Dimmable
Bypass no Ballast
Wattage - 14w (32w fluorescent equivalent)
Bulb Type - 4' T8
Length - 47.78"
Diameter - 1.02"
Lumens - 1,800lm
Lens - Polycarb Nano
Base - Bi-Pin G13
Rated Life - 50,000 hrs
CRI - 80
- Solid state replacements for 4 ft. T8 or G13 Base linear fluorescent
- Single-end powered, operates on 120-277v line voltage
- No external ballast or driver required
- Up to 50% instant energy savings
- Existing fixture maintains original UL compliance per UL1598C listing
- For use with non-shunted tombstone lamp holders
- Not for use in airtight fixtures
- 5 year factory warranty (limited)
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
| Lens Material | -
| Nano-Polycarb | -
-
-
- Dimmable
-
| -
- No
| -
-
-
| Ballast Bypass | Non-Shunted Tombstones required | -
-
-
- Item Style
-
| -
- T8
-
| -
-
-
- Manufacturer
-
| -
| EiKO | Warranty-
| -
| 5 Year Factory Warranty (limited) | -
-
-
- Average Life
| 50,000 Hours | -
-
-
- Bulb Base
-
| -
- G13
| -
-
-
| Voltage | -
| 120-277 Volts | -
-
-
- CRI
| >80 | -
-
-
- Color Temp. (K)
-
| -
5000K-
| -
-
-
| Approx. Initial Lumens | -
| 1,800LM | -
-
-
- EiKO Product Number
| -
- 09734
| -
-
-
- Finish
| -
- Frosted
| -
-
-
-
|
|
|
|
