Part Number: 13142
Part Number Description: LHC1-PS150-50-U
0-10V/Dimmable
Selectable Wattage - 150/130/110/90w Watts
Voltage - 120-277V
Color Temp - 5000K
Lumens - 21,000/18,200/15,400/12,600lm
Beam Angle - 90°
Avg. Rated Life - 50,000 Hours
CRI - >80
Length - 14 3/16" (360mm)
Width - 11" (280mm)
Height - 2 13/15" (71.3mm)
- Compact design, easy one person installation with lightweight compact size, while also reducing packaging waste
- Easily add controls anytime without the need for additional wiring; includes screw-in receptacle for Standalone sensors or Networked lighting controls
- Die-cast aluminum style with molded heatsink fins for enhanced performance and heat dissipation
- Powerset feature allows for multiple lumen stops out of the box
- Includes V-Hook and aircraft cable for suspension installation
- Optional: Add additional Chain Kit, Pendant Mount, or Threaded Rod Surface Mount Kit for greater install flexibility: Sold Separately!
- 0-10V dimming, with dim-to-off/Surge Protection: 6kV
- White powder coated, die-cast aluminum construction, polycarbonate lens
- Equivalent/Replaces: 4 Lamp 4ft 32W T8, 250HID (at 90W), 6 Lamp 4ft 32W T8, 4 lamp 4ft 54W T5, 400W HID (at 150w)
- UL Certified for USA and Canada, RoHS Compliant, FCC Compliant, ICES-005 Compliant, Damp Location Rated, T20 Exempt
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
- Voltage Rating/Type
| -
| 120-277V | -
-
-
- Lens
| -
| Polycarbonate | -
-
-
| Selectable Wattage | -
| 150 Watts/130 Watts/110 Watts/90 Watts | -
-
-
- Lumens per Watt
-
| -
| Up To 140LPW | -
-
-
Selectable Lumens-
| -
| 21,000LM/18,200LM/15,400LM/12,600LM | -
-
-
- CCT
| -
| 5000K | -
-
-
- CRI/Power Factor/THD
| -
| >80/>0.9/<20% | -
-
-
Avg. Rated Life-
| -
- 50,000 Hours
-
| -
-
-
- Ambient Operating Temp Range
-
| -
- -40° C (-40° F) to 50° C (122° F)
-
| -
-
-
| Dimmable | -
| YES/0-10V | -
-
-
-
|
|
|
|
