Part Number: HD016VCR-8
DISCONTINUED - STOCK CHECK!
H-Line: Bi Level Motion Sensor (Internal)
Operating Voltage - DC 10.5-15V
Stand-By Power - <0.5W
Detection Area - 50% / 100%
Hold Time - 5s / 30s / 1min / 10min
Daylight Threshold - 2Lux / 10Lux / 50Lux / Disable
Stand-By Period - 0s / 30s / 20min +
Stand-By Dimming Level - 10% (1.9+0.2V) / 20% (2.9+0.2V) / 30% (3.9+0.2V) / 50% (5+0.2V)
Microwave Frequency - 5.8GHz + 75 MHz
Microwave Power - <0.3mW
Mounting Height - Max. 16ft (Ceiling Mounted)
Motion Detection - 0.5~1m/s
Detection Range - DxH (Radius) 3-7 mx4m/9.84-22.97%ftx 13.12ft. (ceiling mounted)
Control Method - ON/OFF 0-10V Dimming
Operating Temperature: -40°F to +176°F
IP Rating - IP20
Detection Angle - 150°(Wall Mounted) 360° (Ceiling Mounted)
Warranty - 3 Year Limited Factory
Function Setting - Dial Setting
