Part Number: HD406VRH-D-WH
H-Line: Bi Level Motion Sensor
1/2" Knockout
Operating Voltage - 120-277Vac, 50/60Hz
Switching capacity - Max. 3.0A @ 120Vac, 50/60Hz, Max. 2.0A @ 277Vac, 50/60Hz
Stand-By Power - >1W
Detection Area - 25% / 50% / 75% / 100%
Hold Time - 5s / 30s / 1min / 3min / 5min / 5min / 10min / 20min / 30min
Daylight Threshold - 2Lux / 10Lux / 30Lux / 50Lux / 80Lux / 120Lux / Disable
Stand-By Period - 0s / 10s / 30s / 1min / 5min / 10min / 30min +
Stand-By Dimming Level - 10% / 20% / 30% / 50%
Microwave Frequency - 5.8GHz + 75 MHz
Microwave Power - <1mW
Mounting Height - Max. 15m (Ceiling Mounted)
Detection Range - Max.14m
Control Line - Brown L, Blue N, Yellow L, Black - , Red +
Operating Temperature: -22°F to +140°F
IP Rating - IP65
Detection Angle - 30°-50°
Safety Standard - EN61347-1 EN61347-2-13 EN60598-1
|
|
|
