Part Number: LED-RSCN-4FT-3P50-5CCT
0-10V/Dimmable
Selectable Wattage - 50/40/30w
Voltage - 120-277v
Selectable CCT - 30/35/40/50/65K
Lumens - 6,500/5,200/3,900lm
Projected Life (L70) - 50,000 Hours
Beam Angle - 130°
Included Accessories/Sensors - NONE
Finish - White
Length - 48"
Width - 5.4"
Height - 4.7"
- Aluminum housing finished with corrosion free powder coat
- Available with or without bi-level microwave or ultrasonic sensor, Emergency Backup Available (sold separately)
- Surface Mount into 3O or 4O j-box, Conduit feed from the side of the fixture
- 1/2" Knockout on both ends of the fixture
- Lens: Round Acrylic Frosted, Flicker Free
- UL Listed, DLC Premium Listed, Approved for CA T24, FCC CFR 47, GCC Part 15, Subpart B:2017, IP Dating: Damp Location (IP44)
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
- Voltage Rating
| -
- 120-277V
| -
-
-
| Finish | -
| White | -
-
-
| Selectable Wattage | -
| 50 Watts/40 Watts/30 Watts | -
-
-
| Beam Angle | -
- 130°
| -
-
-
- Lumens
-
| -
| 6,500LM/5,200LM/3,900LM | -
-
-
| Selectable CCT | -
| 3000K/3500K/4000K/5000K/6500K | -
-
-
- CRI
-
| -
| >80 | -
-
-
- Projected Life (L70)
| -
50,000 Hours-
| -
-
-
| Thermal | -
- -40°F to 122°F
| -
-
-
- Lens
| -
| Frosted | -
-
-
-
|
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Pre-Installed Factory Add-On's (Fee's/Lead Times Vary):
90 Minute Emergency Backup (internal 8W)
Ultrasonic Sensor
Bi-Level Motion Sensor and Daylight Sensor
ENVISION NLS Bluetooth Control: PIR/Daylight/Zoning
SILVAIR Enable: Bluetooth Control: PIR/Daylight/Zoning/Monitoring
20KV Surge Protector
