Part Number: 7705
Part Number Description: LED-FXTRTF30/2X4/840
0-10V/Dimmable
Wattage - 30w
Voltage - 120-277v
Color Temp - 4000K
Lumens - 3,900lm
Beam Angle - 120°
Avg. Rated Life - >50,000 Hours
Finish - White/Frosted
Replaces/Equivalent - 90-100W
Height - 3.62"
Length - 47.76"
Width - 23.78"
- NaturaLED Retrofit Troffers are the perfect solution for your interior lighting needs
- The Troffers are available in 2'x2' and 2'x4' dimensions for T-Bar and Grid ceiling applications
- Easy installation for retrofit replacement and maximum energy savings
- Material: Steel and PC lens, Surge Protection: 2.5KV, Voltage Frequency: 50/60Hz
- Mounting: Recessed
- UL Listed for dry/damp locations
- DLC, UL Certified, FCC Compliant, LM79, LM80, RoHS Compliant, CA Title 24
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
- Voltage Rating
-
| -
- 120~277
-
| -
-
-
| Material/Lens Material | -
| Steel/PC Lens | -
-
-
| Wattage | -
| 30 Watts | -
-
-
| Dimmable | -
| YES/0-10V/Dimmable | -
-
-
| Lumens | -
| 3,900LM | -
-
-
- Color Temp
| -
| 4000K | -
-
-
- CRI/Power Factor/Beam Angle
| -
80/>0.9/120°
| -
-
-
Avg. Rated Life-
| -
50,000 Hours-
| -
-
-
- Replaces
| 90-100 Watt | -
-
-
- Ambient Operating Temp Range
-
| -
| -4° F to 104° F | -
-
-
- Approvals
-
| -
| DLC, cULus, LM79, LM80, FCC, RoHS Compliant, CA Title 24 | -
-
-
-
|
|
|
|
 |
|
 |
|
