Part Number: L-0113
Description: SS-WK0412-120/100/90W-H-TCP
0-10V/Dimmable
5-Power Selectable/Wattage - 90W/100W/120W
Voltage - 120-277v
Selectable CCT - 30/40/50K
Lumens - 11,200/14,000/16,800lm
Beam Angle - Type IV
BUG - B3-U5-G5
Average Rated Life (L70) - 70,000 Hours
Finish - Bronze
Height - 9.27"
Width - 14.21"
Depth - 7.31"
- EnVisionLED Full-Line: Traditional Wall Pack; Sturdy die-cast aluminum housing finished with corrosion free powder coat
- Traditional metal-halide wall pack size
- Lens: Glass Lens, Instant-On to full brightness, 0-10V Dimmable
- UL Certified, DLC Listed, ROHS Compliant, Approved for CA T24, FCC CFR 47, GCC Part 15, Subpart B:2017,Wet Location Rated, Impact Rating: IK08
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
| Voltage Rating | -
| 120-277V | -
-
-
| Beam Angle/BUG | -
Type IV/B3-U5-G5
| -
-
-
| Wattage/5-Power Selectable | -
| 80 Watts/100 Watts/120 Watts | -
-
-
| Power Factor | -
- >0.9
| -
-
-
| Knockouts | -
| Five (5) 1/2" Knockouts | -
-
-
| Photocell | -
| Accessory | -
-
-
| Lumens | 11,200LM/14,000LM/16,800LM | -
-
-
| Selectable 3-CCT | -
| 3000K/4000K/5000K | -
-
-
- CRI
-
| -
| >80 | -
-
-
- Dimmable
| -
| 0-10V | -
-
-
| Lens | -
| Glass | -
-
-
| Operating Temperature | -
| -40° F to 122° F | -
-
-
| Finish | Bronze | -
-
-
-
|
|
|
|
 |
|
 |
|
