Part Number: 13632 Part Number Description: CSX1-2PS25-FCCT-H
0-10V/Dimmable
Selectable Wattage - 25/20/15w Voltage - 120-347v Selectable CCT - 35/40/50K Selectable Lumens - 3,250/2,600/1,950lm Avg. Rated Life (L70) - 100,000hrs Finish - White/Frosted Replaces/Equivalent - 2 Lamp 17W Fluorescent
Length - 22.2" (564mm) Width - 2.8" (72mm) Height - 2.5" (64mm)
- Unique tool-less entry allows for the lens and LED board to be easily removed, allowing quick access to the driver, simply squeeze the sides together for access.
- Controls ready makes adding controls quick and easy. Includes snap-in receptacle for Standalone and Networked Lighting Controls.
- Available in 2ft, 4ft, and 8ft versions, 2 X 1/2" knockouts on each end, Junction box cover plate included
- Accessories: Linear alignment plate accessory makes row mounting quick and easy, V-Hook and Chain kit accessory available for suspension mounting (sold separately)
- PowerSet feature allows for multiple "set and forget" lumen stops in each fixture
- FieldCCeT feature allows for multiple "set and forget" CCT options in each fixture
- UL Listed for dry/damp locations, RoHS Compliant, FCC Compliant, ICES-005 Compliant, DLC-Standard (#S-ZNW69S), DLC-P(#S-BYZ6UK)
- DesignLights Consortium® Qualified - meets DLC requirements for efficacy and lumen maintenance
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
- Voltage Rating
-
| -
- 120-347V
| -
-
-
- Surge Protection
| -
- 2.5KV
| -
-
-
Selectable Wattage | -
25/20/15 Watts | -
-
-
- Dimming
| -
- 0-10V Dimmable
| -
-
-
Selectable Lumens-
| -
3,250LM/2,600LM/1,950LM | -
-
-
Selectable CCT | -
3500K/4000K/5000K | -
-
-
- CRI
-
| -
>80 | -
-
-
Avg. Rated Life(L70) | -
100,000 Hours-
| -
-
-
- Replaces
| 2x 17W T8 | -
-
-
- Ambient Operating Temp Range
-
| -
- -20° C (-4° F) to 50° C (122° F)
-
| -
-
-
Finish | -
- White
| -
-
-
-
|
|
|
|
